DWRK Model

About

Introducing the Darkhorse Work — your ultimate sidekick for heavy-duty hauling. Engineered with rugged precision and built for demanding jobs, the DWRK is designed to handle whatever challenge comes next.

Whether you’re transporting tools, equipment, vehicles, or heavy cargo, the DWRK delivers exceptional durability, strength, and stability you can depend on day after day. From the jobsite to the weekend haul, this trailer is built to work hard, tow confidently, and stand up to the toughest conditions.

features

3500 Series – Standard

  • 2-5/16” Coupler
  • Spring Axle with 4” Drop
  • Tube Main Rails
  • 16” On-Center Floor Crossmembers
  • 16” On-Center Wall Posts and Tube Roof Bows
  • Painted Roof Bows
  • Automotive Grade Undercoating
  • Rubberized Armor-Coated Tongue and Bumpers
  • Flat Front
  • One-Piece Aluminum Roof
  • .030 Exterior Metal
  • Semi-Screwless Exterior with Color Matching Screws on Seams
  • 24” Tall .045 Stoneguard
  • .063 Smooth Fenders
  • Brite Front Corners
  • Brite Wrap Between Front Cast Corners
  • Brite Rear Hoop
  • 3” Aluminum Top Trim
  • 3” Aluminum Bottom Trim
  • Aluminum Side Wall Vents
  • Ramp Door with Flap or Double Rear Doors
  • 36” Solid RV Side Door with Barlock
  • Aluminum Door Holdbacks
  • 3/4” High-Performance Floor
  • 3/8” Plywood Walls with 3/8” Plywood Trim
  • (4) Recessed 5,000 lb. D-Rings with Ramp Door
  • LED Loading Light with Switch Over Rear
  • LED Porch Light by Side Door
  • 7-Way Connector with Backup Tail
  • Breakaway Battery, Box, and Switch for All Brake Axles
  • (2) LED Dome Lights with Switch
  • All LED Lighting
  • 3-Year Limited Warranty
Specification7x14 TA357x16 TA357.5x14 TA357.5x16 TA358.5x20 TA358.5x20 TA528.5x24 TA52
Overall Length18"20"18"20"24"24"28"
Overall Width102"102"102"102"102"102"102"
Overall Height91"91"101"101"101"101"101"
Interior Length14'16'14'16'20'20'24'
Interior Width80"80"86"86"96"96"96"
Interior Height72"72"78"78"78"78"78"
Platform Height20"20"20"20"20"21"21"
Rear Opening Height72"72"72"72"75"*75"*75"*
Rear Opening Width76"76"82"82"92"92"92"
Dist. Between Cables75"75"81"81"91"91"91"
Top of Hitch Ball19"19"19"19"19"20"20"
Hitch Ball Size2 5/16"2 5/16"2 5/16"2 5/16"2 5/16"2 5/16"2 5/16"
Tire SizeST205/75R15ST205/75R15ST205/75R15ST205/75R15ST205/75R15ST225/75R15ST225/75R15
Load RangeCCCCCDD
Wheel Bolt Pattern5-Bolt/4.55-Bolt/4.55-Bolt/4.55-Bolt/4.55-Bolt/4.56-Bolt/5.56-Bolt/5.5
AxlesTandemTandemTandemTandemTandemTandemTandem
Axle Type4" Drop4" Drop4" Drop4" Drop4" Drop4" Drop4" Drop
BrakesElectricElectricElectricElectricElectricElectricElectric
GVWR7,000 lbs.7,000 lbs.7,000 lbs.7,000 lbs.7,000 lbs.9,990 lbs.9,990 lbs.
Hitch Weight200 lbs.230 lbs.170 lbs.180 lbs.400 lbs.450 lbs.500 lbs.
Curb Weight2,300 lbs.2,420 lbs.2,430 lbs.2,680 lbs.3,250 lbs.3,400 lbs.4,000 lbs.
Payload Capacity4,700 lbs.4,580 lbs.4,570 lbs.4,320 lbs.3,650 lbs.6,950 lbs.5,990 lbs.

Specifications are based on the 1500 Series.  Specifications, features, and standards are subject to change without notice
